The Algorithm...
- Assessment, support, and cause-specific treatment proceed together; involve cardiology / the shock team early.
01 Assess Perfusion / Respiratory Status
-
Perfusion: BP / pulse, mentation, extremity temperature, capillary refill, and urine output. Cool / clammy skin, confusion, or oliguria raises concern—even with a preserved BP.
-
Breathing: Respiratory effort, SpO₂, crackles, and fatigue. Establish monitoring / IV access; oxygen for hypoxemia.
-
Assess lactate, creatinine, and liver-function trends. Low EF or edema alone does not establish shock. See Recognition.
02 Is The Heart The Cause?
-
History / Exam: Chest pain, recent MI, known HF, palpitations; assess rhythm, JVP, edema, crackles, and a new murmur.
-
ECG: Ischemia / infarction, tachyarrhythmia, bradycardia, or AV block?
-
Cardiac / Lung POCUS: LV versus RV dysfunction, major valve abnormality, pericardial effusion, and pulmonary congestion. Obtain urgent formal echo when needed.
-
Consider PE, tamponade, sepsis, or hemorrhage when the findings do not fit isolated pump failure. See Evaluation.
03 What Support Does The Patient Need?
-
Hypotensive With Hypoperfusion: Start norepinephrine; titrate to pressure and organ response.
-
Adequate BP, Persistent Low Output: Reassess filling and cardiac function; consider dobutamine. Some patients require both pressure and inotropic support.
-
Congested: Elevated JVP, edema, or pulmonary congestion → consider IV loop diuresis while maintaining perfusion. Hypotension does not automatically indicate a fluid deficit.
-
Underfilled: A small fluid challenge may be appropriate when the assessment supports it; reassess immediately, especially with RV dysfunction. See Fluids Or Diuresis.
-
Respiratory Failure: Consider CPAP / BiPAP for pulmonary edema when airway protection and hemodynamics permit. Intubate for failing oxygenation / ventilation or airway protection; prepare circulatory support before induction. See Airway.
04 Treat The Cause / Escalate
-
ACS With Shock: Urgent coronary evaluation / revascularization pathway.
-
Causative Unstable Rhythm: Cardioversion, pacing, or rhythm-specific treatment.
-
New Murmur / Abrupt Post-MI Deterioration: Urgent echo and cardiac surgical assessment for a mechanical complication.
-
Persistent hypoperfusion or escalating infusions → reassess the cause; arrange shock-center transfer / selected mechanical support. See Definitive Treatment.
05 Reassess / Destination
-
Recheck mentation, skin perfusion, urine output, BP, respiratory support, and lactate trend. A better BP without better perfusion is an incomplete response.
-
Cath Lab / OR: Time-sensitive coronary or mechanical intervention.
-
ICU / Shock Center: Ongoing shock, vasoactive infusions, or advanced support. See Disposition.
Recognize Cardiogenic Shock
Hypoperfusion From A Cardiac Cause?
-
Cardiogenic shock is inadequate circulation from cardiac dysfunction with clinical or biochemical evidence of tissue hypoperfusion.
-
BP: SBP <90 or MAP <65 mm Hg raises concern, but hypotension is not required. Compensatory vasoconstriction can preserve BP despite inadequate flow.
-
EF: A chronically low EF does not establish shock; preserved LV EF does not exclude RV failure or an acute mechanical problem.
-
Assess the current physiology and trajectory rather than the HF diagnosis alone. ACC 2025.
Evidence Of Organ Hypoperfusion / Dysfunction
-
Brain: New confusion, agitation, lethargy, or reduced responsiveness.
-
Skin: Cool / clammy extremities, delayed capillary refill, mottling, weak pulses.
-
Kidneys: Falling urine output, oliguria, or rising creatinine.
-
Liver / Metabolic: Rising transaminases, lactate, or metabolic acidosis.
-
Interpret trends against baseline. These findings are supportive, sometimes late, and not individually diagnostic; renal / hepatic abnormalities may also reflect congestion. ACC 2025 · AHA — Right Heart Failure.
SCAI Stage — Describe Severity And Trajectory
| Stage | Description |
|---|---|
| A — At Risk: | Predisposing cardiac disease without current instability or hypoperfusion. |
| B — Beginning: | Hemodynamic instability, but systemic perfusion remains adequate. |
| C — Classic: | Hypoperfusion; pharmacologic or mechanical support is needed. |
| D — Deteriorating: | Initial support fails to restore perfusion; requirements increase. |
| E — Extremis: | Actual or impending circulatory collapse despite escalating support. |
-
Reassess the stage as treatment proceeds. Classification communicates severity; it does not replace the cause-specific assessment or require every listed laboratory abnormality. SCAI 2022.
Identify The Cause / Hemodynamic Pattern
Immediate Cardiac Causes
-
ACS: Chest discomfort, ischemic ECG findings, or unexplained acute ventricular dysfunction. Both STEMI and NSTEMI may cause shock.
-
Dysrhythmia: Sustained tachyarrhythmia, marked bradycardia, or high-grade AV block contributing to poor output.
-
Mechanical / Valve: Abrupt deterioration after MI, new murmur, or sudden pulmonary edema → assess acute MR, ventricular septal rupture, or another major valve lesion.
-
Pump Failure: Acute decompensated cardiomyopathy, myocarditis, or other acute myocardial dysfunction.
-
Alternative / Mixed Shock: Sepsis with myocardial dysfunction, hemorrhage, PE, or tamponade. A poor EF does not establish the entire explanation. ACC 2025 · AHA — Mechanical Complications.
Focused History / Examination
-
Review onset, chest symptoms, prior HF / coronary or valve disease, recent MI / procedure, medications, and baseline function.
-
Assess perfusion alongside JVP, crackles, edema, rhythm, and murmurs.
-
Congestion and perfusion are separate assessments. A patient may be congested yet adequately perfusing, congested and shocked, or hypoperfused without prominent lung findings. AHA/ACC/HFSA 2022.
ECG / Cardiac And Lung POCUS
-
ECG: Ischemia / infarction, ventricular arrhythmia, bradycardia, or conduction block; compare prior tracings. Consider right-sided leads with suspected RV infarction.
-
LV: Global versus regional dysfunction; assess chamber size and major valve abnormalities.
-
RV: Size, contractility, and septal position; assess RV-dominant or biventricular failure.
-
Pericardium / Lungs: Effusion with possible tamponade physiology, B-lines, pleural fluid, or an alternative pulmonary problem.
-
Obtain urgent formal echocardiography when valve anatomy, mechanical disease, or the hemodynamic explanation remains uncertain. RV dilation alone does not diagnose PE; pericardial fluid alone does not diagnose tamponade. ACC 2025 · AHA — Right Heart Failure.
Laboratory Testing / Additional Imaging
-
Obtain CBC, electrolytes / renal function, magnesium, liver tests, lactate, and troponin; blood gas when respiratory failure or significant acidosis is present.
-
Troponin supports myocardial-injury assessment; interpret with ECG, symptoms, and trajectory rather than diagnosing ACS from the value alone.
-
Consider CXR for congestion / another pulmonary diagnosis and cultures / infectious testing when mixed septic shock is plausible.
-
Do not delay time-sensitive coronary or mechanical intervention for a complete laboratory panel. ACC 2025.
Support Pressure, Flow, And Oxygenation
Pressure Is Not The Same As Flow
-
Low output: The circulation may maintain BP through vasoconstriction while organ blood flow remains inadequate.
-
Vasopressor: Supports arterial pressure; excessive vasoconstriction can also increase the failing ventricle’s workload.
-
Inotrope: Supports contractility / output; dobutamine and milrinone can also lower vascular resistance and BP.
-
Practical implication: Hypotension may require norepinephrine, persistent low output may require an inotrope, and some patients require both. A better MAP without better perfusion is an incomplete response. ACC 2025 — Pharmacologic Management.
Norepinephrine — Hypotensive Shock
-
A reasonable initial vasopressor for most hypotensive cardiogenic-shock patients; not a medication every patient with low EF needs.
-
Example start: 0.05–0.1 mcg/kg/min IV, titrated to pressure and perfusion. This is a starting range, not a maximum; follow standardized infusion / monitoring protocols.
-
Initial MAP around 65 mm Hg is a practical starting goal, then individualize to baseline pressure and organ response.
-
Use the lowest effective dose; persistent hypoperfusion despite restored pressure requires reassessment of output, congestion, and the cause. ACC 2025.
Dobutamine / Milrinone — Persistent Low Output
-
Dobutamine: Consider when inadequate cardiac output persists after pressure and filling have been assessed. An example starting infusion is 2.5–5 mcg/kg/min IV, titrated to response.
-
Watch for tachyarrhythmia, ischemia, and hypotension; concurrent norepinephrine may be necessary.
-
Milrinone: A selected alternative with inotropic and vasodilator effects. Its longer action and renal accumulation make titration less forgiving in hypotension / AKI; dosing requires renal and hemodynamic assessment. AHA/ACC/HFSA — IV Inotropes.
-
DOREMI: In 192 patients, milrinone did not significantly improve the primary composite outcome compared with dobutamine. Neither is a proven universal winner. Mathew 2021.
Other Vasoactive Choices
-
Epinephrine: Remains a selected rescue option, but not the default substitute for norepinephrine. A small post-MI shock trial found more refractory shock and lactic acidosis with epinephrine; it did not settle every clinical scenario. OptimaCC 2018.
-
Vasodilators: Selected patients with adequate pressure and excessive afterload may benefit under closely monitored specialist care; avoid carrying the hypertensive pulmonary-edema nitrate pathway into hypotensive shock.
-
Pure Vasoconstriction: Phenylephrine may raise BP while worsening output; it is not the usual primary infusion for pump failure. ACC 2025.
Fluids Or Diuresis?
-
Underfilled: Consider a small crystalloid challenge only when the history / examination / echo supports inadequate filling. For example, 250 mL followed by immediate reassessment—not automatic repeated liters.
-
Congested And Perfusing: Treat congestion with IV loop diuretics; this may be decompensated HF without cardiogenic shock.
-
Congested And Hypoperfused: Support pressure / output and address congestion together. Diuretics alone may be insufficient, but hypotension does not automatically mean the patient needs fluid. AHA — Right Heart Failure.
-
Why kidney function may improve: Lower venous pressure can relieve renal congestion and improve the pressure gradient through the kidney. More fluid may worsen that problem; a rising creatinine does not independently establish dehydration. AHA — Cardiorenal Syndrome.
-
Follow BP, perfusion, urine output, electrolytes, and congestion. Reassess a creatinine rise in context rather than reflexively stopping decongestion or adding fluid. AHA/ACC/HFSA — Decongestion.
RV-Dominant Failure — Avoid Automatic Fluid Loading
-
The RV needs adequate filling, but a distended RV may already be overfilled. Additional volume can worsen septal shift, reduce LV filling, and lower output.
-
Assess volume status, RV function, pulmonary pressures / suspected cause, and perfusion. Select fluid, decongestion, and vasoactive support accordingly.
-
Correct hypoxemia and significant acidemia; avoid unnecessary increases in intrathoracic pressure. RV infarction needs coronary treatment; PE requires the obstructive-shock / reperfusion pathway.
-
Uncertain or refractory RV failure warrants early specialist input and consideration of invasive hemodynamics. AHA — Right Heart Failure.
Respiratory Support / Intubation
-
Treat hypoxemia and excessive respiratory effort. Consider CPAP / BiPAP for pulmonary edema when airway protection, cooperation, and hemodynamics permit.
-
The strong NIV evidence for pulmonary edema does not automatically apply to cardiogenic shock: These patients were generally excluded from the trials. Reassess BP and perfusion immediately after positive pressure begins. ERS/ATS — Cardiogenic Pulmonary Edema.
-
Intubation: Failed oxygenation / ventilation, exhaustion, or loss of airway protection. Induction and positive pressure can precipitate collapse; prepare hemodynamic support, preoxygenate, and use an experienced airway team.
-
Follow the RSI pathway. Do not delay necessary airway control, but do not intubate solely because shock is present. ACEP — Endotracheal Intubation.
Correct The Cause / Escalate Early
ACS / Dysrhythmia / Mechanical Disease
-
ACS With Shock: Emergency coronary angiography / culprit-vessel revascularization when indicated. Routine treatment of additional nonculprit vessels during the same shock procedure is not the preferred strategy. ACC/AHA — ACS 2025.
-
Unstable Dysrhythmia: Cardioversion, pacing, or appropriate rhythm treatment. Distinguish a causative arrhythmia from compensatory sinus tachycardia.
-
Mechanical Complication: Suspected papillary muscle rupture / acute severe MR, septal rupture, or free-wall rupture → immediate echo and cardiac surgical / structural-heart assessment. Pressors do not repair a mechanical lesion. AHA — Mechanical Complications Of MI.
-
Nonischemic Pump Failure: Early advanced-HF / shock-team involvement; assess recovery potential and the need for temporary support. ACC 2025.
When Initial Treatment Is Not Enough
-
Escalating vasopressor / inotrope requirements, persistent oliguria, worsening mentation / acidosis, or recurrent arrhythmia: Reassess the cause and activate the shock team / transfer pathway.
-
Consider a pulmonary artery catheter when bedside findings do not adequately define LV versus RV failure, filling pressures, or response to treatment.
-
Invasive measurements can direct fluid removal, inotropes, and device selection. They supplement clinical assessment; do not delay immediate treatment or transfer for a catheter. AHA/ACC/HFSA — Cardiogenic Shock · ACC 2025.
Temporary Mechanical Circulatory Support
-
Consider when adequate organ perfusion cannot be maintained with initial treatment or selected high-risk anatomy / physiology warrants earlier support. Device choice depends on LV, RV, or biventricular failure, oxygenation, anatomy, and the intended bridge to recovery or further therapy.
-
Microaxial LV Pump: An option for selected infarct-related shock—not an automatic device for every low EF or hypotensive patient.
- DanGer-Shock: Among 355 analyzed STEMI-shock patients, 180-day mortality was 45.8% versus 58.5% with pump versus standard care. The composite safety outcome was 24.0% versus 6.2%. Benefit and harm both matter; this was not an all-comers HF population. Møller 2024.
-
VA-ECMO: Provides circulatory and oxygenation support, but routine early use in infarct-related shock did not improve 30-day survival in ECLS-SHOCK and increased bleeding / vascular complications. Selected rescue remains a separate decision. Thiele 2023.
-
IABP: Not an automatic step for undifferentiated cardiogenic shock; may have a selected bridging role, including certain mechanical complications. AHA — Mechanical Complications.
Reassessment / Disposition
Is Perfusion Actually Improving?
-
Reassess mentation, skin perfusion, urine output, MAP, respiratory support, and vasoactive requirements after changes.
-
Trend lactate, creatinine, electrolytes, acid–base status, and liver tests according to severity. Repeat focused echo when the response is unexpected.
-
Consider invasive arterial pressure monitoring for ongoing shock / titrated infusions. Reassess mixed physiology and unresolved ischemia, obstruction, or mechanical disease when support requirements rise.
-
A better BP with persistent organ hypoperfusion is not successful resuscitation. ACC 2025 — Reassessment.
Cath Lab / OR
-
Coronary ischemia or a mechanical lesion requiring immediate intervention.
-
Arrange definitive treatment while supporting circulation; ICU admission must not delay a needed procedure. ACC/AHA — ACS 2025 · AHA — Mechanical Complications.
ICU Admission / Shock Center
-
Ongoing hypoperfusion, vasoactive infusions, advanced respiratory support, unstable rhythms, or mechanical-support consideration.
-
Transfer early when the required cardiac / surgical support is unavailable locally. Communicate the cause, LV / RV findings, SCAI stage, trajectory, current infusions, and treatment response.
-
Clarify goals of care and the purpose of escalation while continuing indicated resuscitation. ACC 2025 — Shock Teams / Transfer.
Monitored Admission
-
Appropriate for selected preshock patients or after sustained resolution of shock, depending on residual risk and local monitoring capability.
-
Confirmed cardiogenic shock requires inpatient care; an initially improved BP is not an ED discharge criterion. AHA/ACC/HFSA 2022.
In The Pit
-
Hypoperfusion: Cool / clammy, confused, or oliguric → assess shock despite a reasonable BP; ECG + cardiac / lung POCUS.
-
Correctable Cause: Ischemic ECG, unstable rhythm, or new murmur → urgent coronary, rhythm, or mechanical-complication treatment.
-
Pressure / Flow: Norepinephrine for hypotensive shock; persistent low output despite adequate pressure → reassess filling / consider dobutamine.
-
Fluids Or Diuresis: Congested → decongest with perfusion support; underfilled → small challenge and reassess. RV failure is not an automatic fluid indication.
-
Respiratory Failure: Support ventilation; anticipate collapse with induction / positive pressure.
-
Deteriorating: Escalating infusions or worsening organ perfusion → shock team / transfer / mechanical-support assessment.
